MS46524B 是 4 端口高性能 ShockLine 矢量網絡分析儀系列。 此高性能系列擁有不可超越的高價值與高性能，能夠提供同類產品中最佳的動態范圍，能夠降低在多種測試應用（最高 43.5 GHz）中的測試成本并加快上市速度。 這些測試應用包括設計和制造多端口移動網絡設備、移動設備、汽車線纜、高速數據互連與系統集成組件。
MS46524B配置選件10，選件20，或選件43，為ShockLine系列帶來了從射頻到微波頻率的測量功能。這些頻率選件結合強大的ShockLine軟件，為無源器件測試提供了極具成本效益挑戰性的解決方案。
對于需要時域分析的應用，選件2和選件22都可使用。選件2可使MS46524B提供實時的帶通和低通時域功能。低通時域具有試驗數據報告，能夠顯示隨距離或時間變化的實際阻抗。選件22使MS46524B具備基于文件的信號完整性（SI）工具，可調試SI問題和驗證電路模型。
MS46524B-010 VNA可添加附加選件。選件51和61，分別為源和接收機訪問環路和偏置節選件，給予自定義測試設置最大的靈活性。源和接收機訪問環路改善儀器的本底噪聲，降低接收機的壓縮點，允許具有高動態范圍的要求的DUT測試。偏置節為測試時需要直流偏置的器件測試提供直流電源接口。
MS46524B 系列采用 3U 機箱封裝，使用與 ShockLine 系列其他產品相同的 GUI、軟件、命令語法、驅動程序和編程環境。
| 選項 | 說明 |
| MS46524B-010 | 50 kHz to 8.5 GHz |
| MS46524B-020 | 50 kHz to 20 GHz |
| MS46524B-043 | 50 kHz to 43.5 GHz |
Universal Fixture Extraction (UFX) software option provides advanced de-embedding tools for test fixture extraction
| Model Number | Description |
| MN25208A | 2-port USB SmartCal Module, 300 kHz to 8.5 GHz (available with connector options: -001 N(f), -002 K(f), -003 3.5 mm(f) |
| MN25408A | 4-port USB SmartCal Module, 300 kHz to 8.5 GHz (available with N(f) connectors) |
| MN25218A | 2-port USB SmartCal Module, 1 MHz to 20 GHz (available with K(f) connectors) |
| MN25418A | 4-port USB SmartCal Module, 300 kHz to 20 GHz (available with K(f) connectors) |
| 36585K-2M | K Precision AutoCal Module, 70 kHz to 40 GHz, K(m) to K(m) |
| 36585K-2F | K Precision AutoCal Module, 70 kHz to 40 GHz, K(f) to K(f) |
| 36585K-2MF | K Precision AutoCal Module, 70 kHz to 40 GHz, K(m) to K(f) |
| 2000-1809-R | Serial to USB Adapter (required for use with 36585 AutoCal module) |
| Model Number | Description |
| MN4765B-0040 | 2-port, 800 nm to 890 nm, O/E Calibration Module, 70 kHz to 40 GHz |
| MN4765B-0042 | 2-port, 800 nm to 1700 nm, O/E Calibration Module, 70 kHz to 40 GHz |
| MN4675B-0043 | 2-port, 800 nm to 1700 nm, 1300 nm to 1330 nm, and 1530 nm to 1620 nm, O/E Calibration Module, 70 kHz to 40 GHz |
| MN4765B-0070 | 2-port, 1480 nm to 1620 nm, O/E Calibration Module, 70 kHz to 70 GHz |
| MN4765B-0071 | 2-port, 1300 nm to 1330 nm, O/E Calibration Module, 70 kHz to 70 GHz |
| MN4765B-0072 | 2-port, dual 1530 nm to 1620 nm and 1300 nm to 1330 nm, O/E Calibration Module, 70 kHz to 70 GHz |
| Model Number | Description |
| 3650A | SMA/3.5 mm Calibration Kit, Without Sliding Loads, DC to 26.5 GHz, 50 Ω |
| 3650A-1 | SMA/3.5 mm Calibration Kit, With Sliding Loads, DC to 26.5 GHz, 50 Ω |
| 3652A | K Connector Calibration Kit, Without Sliding Loads, DC to 40 GHz, 50 Ω |
| 3653A | N Connector Calibration Kit, Without Sliding Loads, DC to 18 GHz, 50 Ω |
| OSLN50A-8 | Precision N Male Open/Short/Load Mechanical Calibration Tee, DC to 8 GHz, 50 Ω |
| OSLNF50A-8 | Precision N Female Open/Short/Load Mechanical Calibration Tee, DC to 8 GHz, 50 Ω |
| TOSLN50A-8 | Precision N Male Through/Open/Short/Load Mechanical Calibration Tee, DC to 8 GHz, 50 Ω |
| TOSLNF50A-8 | Precision N Female Through/Open/Short/Load Mechanical Calibration Tee, DC to 8 GHz, 50 Ω |
| OSLN50A-18 | Precision N Male Open/Short/Load Mechanical Calibration Tee, DC to 18 GHz, 50 Ω |
| OSLNF50A-18 | Precision N Female Open/Short/Load Mechanical Calibration Tee, DC to 18 GHz, 50 Ω |
| TOSLN50A-18 | Precision N Male Through/Open/Short/Load Mechanical Calibration Tee, DC to 18 GHz, 50 Ω |
| TOSLNF50A-18 | Precision N Female Through/Open/Short/Load Mechanical Calibration Tee, DC to 18 GHz, 50 Ω |
| TOSLK50A-20 | Precision K Male Through/Open/Short/Load Mechanical Calibration Tee, DC to 20 GHz, 50 Ω |
| TOSLKF50A-20 | Precision K Female Through/Open/Short/Load Mechanical Calibration Tee, DC to 20 GHz, 50 Ω |
| TOSLK50A-40 | Precision K Male Through/Open/Short/Load Mechanical Calibration Tee, DC to 40 GHz, 50 Ω |
| TOSLKF50A-40 | Precision K Female Through/Open/Short/Load Mechanical Calibration Tee, DC to 40 GHz, 50 Ω |
| TOSLK50A-43.5 | Precision K Male Through/Open/Short/Load Mechanical Calibration Tee with S1P data, DC to 43.5 GHz, 50 Ω |
| TOSLKF50A-43.5 | Precision K Female Through/Open/Short/Load Mechanical Calibration Tee with S1P data, DC to 43.5 GHz, 50 Ω |
| Model Number | Description |
| 3663-4 | N Connector Verification Kit |
| 3668-4 | 43.5 GHz K Connector Verification Kit |
